Kluson 6 In Line Revolution Series H-Mount Non-Collared Tuning Machines Gold

Kluson 6 In Line Revolution Series H-Mount Non-Collared Tuning Machines Gold

  • $77.00
    Unit price per
Shipping calculated at checkout.


The Kluson Revolution H-mount 19:1 high ratio tuning machine. Kluson has truly introduced a game changer with the traditional 6 in line footprint and newly designed sealed diecast housing. These state of the art tuning machines are designed to directly retrofit vintage Kluson machines with a push-in bushing, traditional Kluson 6 in line mounting pattern and vintage 11/32 inch peghole. The vintage outline, metal oval button and pin-stripes pay tribute to Kluson heritage while the brand new housing appearance incorporates all the features the modern guitarist demands.High gear ratio guarantees silky smooth operation, fine tuning stability and no backlash all in a sealed one-piece housing. 6 in line tuning machine set for right handed instrument and all mounting hardware is included.-Gear Ratio= 19:1-Gear type= Steel worm and Brass ring-Locking mechanism= N/A-Bushing Type= Push In-Bushing Depth= 5/16 in. (7.5mm)-Bushing O.D.= 11/32 in. (8.8mm)-Bushing I.D.= (1/4 in. (6.5mm)-String Post type= Safe-Ti-Post-String Post Diameter= 1/4 in. (6.35mm)-String Post Height= 1 inch (25.5mm)-String Post Material= Steel-Housing= Diecast-Mount Pattern= Vintage 6 in line Kluson-Comes with all mounting hardware
